# Introduction
You’ve probably typed a question into a search bar and gotten results that matched your words but completely missed your meaning. Or watched a recommendation engine surface something eerily relevant even though you never searched for it directly. The gap between “finding exact words” and “understanding what someone actually means” is what makes a search feature useful.
Vector search closes that gap by representing text as points in high-dimensional space, where geometric proximity encodes semantic similarity. Two sentences can share zero words and still end up neighbors because the model learned that their meanings are close.
This article builds a vector search engine from scratch in Python using only NumPy, so you can see exactly what happens at each step: how embeddings get stored and normalized, why cosine similarity reduces to a dot product, and what the resulting search space actually looks like when you project it down to two dimensions.
You can get the code on GitHub.
# What Is Vector Search?
Traditional keyword search looks for exact word matches. Vector search works differently: it converts documents and queries into numerical vectors called embeddings, then finds the vectors that are closest to each other in high-dimensional space.
The key insight is that closeness in vector space means semantic similarity. Two sentences that mean the same thing — even if they share no words — will have embeddings that are near each other.
The distance metric you use to measure “closeness” is what drives the whole system. The most common one is cosine similarity, which measures the angle between two vectors rather than their absolute distance. This makes it scale-invariant — useful when you care about direction or meaning rather than magnitude or word count.
# Setting Up the Dataset
We’ll work with a set of short product descriptions from a fictional e-commerce catalog. These are pre-embedded as 8-dimensional vectors — a much reduced dimensionality that is realistic enough to demonstrate the concepts.
In a real system, you’d generate these embeddings from a model like sentence-transformers. For this tutorial, we simulate that step with controlled random data that has a clear cluster structure.
import numpy as np
np.random.seed(42)
# Product catalog — 3 semantic clusters: electronics, clothing, furniture
products = [
"Wireless noise-cancelling headphones with 30-hour battery",
"Bluetooth speaker with waterproof design",
"USB-C hub with 7 ports and power delivery",
"4K HDMI cable 6ft braided",
"Mechanical keyboard with RGB backlight",
"Men's slim-fit chino pants navy blue",
"Women's merino wool turtleneck sweater",
"Unisex running jacket lightweight windbreaker",
"Leather chelsea boots for men",
"Organic cotton crew neck t-shirt",
"Solid oak dining table seats 6",
"Ergonomic mesh office chair lumbar support",
"Linen sofa 3-seater natural beige",
"Bamboo bookshelf 5-tier adjustable",
"Memory foam mattress queen size medium firm",
]
# Simulate embeddings with cluster structure
# Cluster centers in 8D space
electronics_center = np.array([0.9, 0.1, 0.2, 0.8, 0.1, 0.3, 0.7, 0.2])
clothing_center = np.array([0.1, 0.8, 0.7, 0.1, 0.9, 0.2, 0.1, 0.8])
furniture_center = np.array([0.2, 0.3, 0.9, 0.2, 0.1, 0.9, 0.3, 0.1])
n_per_cluster = 5
noise = 0.08
embeddings = np.vstack([
electronics_center + np.random.randn(n_per_cluster, 8) * noise,
clothing_center + np.random.randn(n_per_cluster, 8) * noise,
furniture_center + np.random.randn(n_per_cluster, 8) * noise,
])
print(f"Embeddings shape: {embeddings.shape}")
Output:
Embeddings shape: (15, 8)
Each row is a product. Each column is one dimension of its embedding. The product names won’t be used by the search engine; only the embeddings matter.
Image by Author
# Building the Index
The “index” in a vector search engine is just the stored set of normalized embeddings. Normalization is important here because it makes cosine similarity equivalent to a dot product, which is cheaper to compute.
def normalize(vectors: np.ndarray) -> np.ndarray:
"""L2-normalize each row vector."""
norms = np.linalg.norm(vectors, axis=1, keepdims=True)
# Avoid division by zero
norms = np.where(norms == 0, 1e-10, norms)
return vectors / norms
class VectorIndex:
def __init__(self):
self.vectors = None
self.labels = None
def add(self, vectors: np.ndarray, labels: list):
self.vectors = normalize(vectors)
self.labels = labels
print(f"Indexed {len(labels)} items with {vectors.shape[1]}-dimensional embeddings.")
def search(self, query_vector: np.ndarray, top_k: int = 3):
query_norm = normalize(query_vector.reshape(1, -1))
# Cosine similarity = dot product of normalized vectors
scores = self.vectors @ query_norm.T # shape: (n_items, 1)
scores = scores.flatten()
# Get top-k indices sorted by descending score
top_indices = np.argsort(scores)[::-1][:top_k]
return [(self.labels[i], float(scores[i])) for i in top_indices]
index = VectorIndex()
index.add(embeddings, products)
Output:
Indexed 15 items with 8-dimensional embeddings.
The search method does three things: normalizes the query, computes dot products against every stored vector, then sorts by score and returns the top-k results. That matrix multiplication (self.vectors @ query_norm.T) is the entire retrieval step.
# Running Queries
Now let’s test what we’ve built with a few queries. We construct query vectors by starting from one of the cluster centers and adding a little noise to simulate a real query embedding.
def make_query(center: np.ndarray, noise_scale: float = 0.05) -> np.ndarray:
return center + np.random.randn(8) * noise_scale
queries = {
"audio equipment": make_query(electronics_center),
"casual wear": make_query(clothing_center),
"home furniture": make_query(furniture_center),
}
for query_name, q_vec in queries.items():
print(f"\nQuery: '{query_name}'")
results = index.search(q_vec, top_k=3)
for rank, (label, score) in enumerate(results, 1):
print(f" {rank}. [{score:.4f}] {label}")
Output:
Query: 'audio equipment'
1. [0.9856] Wireless noise-cancelling headphones with 30-hour battery
2. [0.9840] USB-C hub with 7 ports and power delivery
3. [0.9829] Mechanical keyboard with RGB backlight
Query: 'casual wear'
1. [0.9960] Men's slim-fit chino pants navy blue
2. [0.9958] Leather chelsea boots for men
3. [0.9916] Women's merino wool turtleneck sweater
Query: 'home furniture'
1. [0.9929] Bamboo bookshelf 5-tier adjustable
2. [0.9902] Linen sofa 3-seater natural beige
3. [0.9881] Solid oak dining table seats 6
Scores close to 1.0 mean near-identical direction in embedding space, which is exactly what you expect for queries constructed from the same cluster center as their target documents.
# Visualizing the Embedding Space
High-dimensional data is hard to reason about visually. Principal component analysis (PCA) projects the 8-dimensional embeddings down to 2D so we can see the cluster structure. We’ll implement a minimal PCA using only NumPy.
The following code computes the 2D PCA projection and plots all product embeddings with labels and cluster colors:
import matplotlib.pyplot as plt
import matplotlib.patches as mpatches
projected = pca_2d(embeddings)
cluster_colors = (
["#4A90D9"] * 5 + # electronics — blue
["#E8734A"] * 5 + # clothing — orange
["#5BAD72"] * 5 # furniture — green
)
cluster_labels = ["Electronics"] * 5 + ["Clothing"] * 5 + ["Furniture"] * 5
fig, ax = plt.subplots(figsize=(6, 4))
ax.scatter(projected[:, 0], projected[:, 1],
c=cluster_colors, s=100, edgecolors="white", linewidths=0.7, zorder=3)
This part projects query vectors into the same space, overlays them, and finalizes the plot:
# Plot query projections
q_projected = pca_2d(
np.vstack(list(queries.values())) - embeddings.mean(axis=0)
)
for (qname, _), (qx, qy) in zip(queries.items(), q_projected):
ax.scatter(qx, qy, marker="*", s=200, color="gold",
edgecolors="#333", linewidths=0.6, zorder=4)
ax.annotate(f"⟵ query: {qname}", (qx, qy),
textcoords="offset points", xytext=(6, -8),
fontsize=7, color="#555555", style="italic")
legend_patches = [
mpatches.Patch(color="#4A90D9", label="Electronics"),
mpatches.Patch(color="#E8734A", label="Clothing"),
mpatches.Patch(color="#5BAD72", label="Furniture"),
mpatches.Patch(color="gold", label="Query vectors"),
]
ax.legend(handles=legend_patches, loc="upper left", fontsize=6)
ax.set_title("Vector Search — Embedding Space (PCA projection)", fontsize=10, pad=10)
ax.set_xlabel("PC 1"); ax.set_ylabel("PC 2")
ax.grid(True, linestyle="--", alpha=0.4)
plt.tight_layout()
plt.savefig("embedding_space_queries_only.png", dpi=150)
plt.show()
Output:
Vector Search — Embedding Space (PCA projection)
The clusters separate cleanly. Each gold star (query vector) lands inside the cluster it was constructed from. This is the geometry that vector search makes use of.
# Visualizing the Similarity Score Distribution
For any given query, it’s useful to see how similarity scores are distributed across the whole index — and not just the top-k. This tells you whether the top result is a clear winner or just marginally better than everything else.
q_vec_furniture = queries["home furniture"]
q_norm_furniture = normalize(q_vec_furniture.reshape(1, -1))
all_scores_furniture = (index.vectors @ q_norm_furniture.T).flatten()
sorted_idx_furniture = np.argsort(all_scores_furniture)[::-1]
sorted_scores_furniture = all_scores_furniture[sorted_idx_furniture]
sorted_labels_furniture = [products[i][:30] + "…" if len(products[i]) > 30
else products[i] for i in sorted_idx_furniture]
# Define bar colors: green for furniture items, gray for others
bar_colors_furniture = []
for i in sorted_idx_furniture:
if i >= 10 and i <= 14: # Furniture items are originally at indices 10-14
bar_colors_furniture.append("#5BAD72") # Green for furniture
else:
bar_colors_furniture.append("#cccccc") # Gray for others
fig, ax = plt.subplots(figsize=(10, 5))
bars = ax.barh(sorted_labels_furniture[::-1], sorted_scores_furniture[::-1],
color=bar_colors_furniture[::-1], edgecolor="white", height=0.65)
ax.axvline(sorted_scores_furniture[2], color="#5BAD72", linestyle="--",
linewidth=1.2, label="Top-3 cutoff")
ax.set_xlim(sorted_scores_furniture.min() - 0.002, 1.001)
ax.set_xlabel("Cosine Similarity Score")
ax.set_title("Query: 'home furniture' — Similarity Across All Products", fontsize=11, pad=12)
ax.legend(fontsize=8)
ax.grid(axis="x", linestyle="--", alpha=0.4)
plt.tight_layout()
plt.savefig("score_distribution_furniture.png", dpi=150)
plt.show()
Output:
Query: ‘home furniture’ — Similarity Across All Products
There’s a visible gap between the furniture cluster (top 5 bars) and everything else. In practice, you’d use this gap to set a similarity threshold below which results are suppressed entirely.
# Wrapping Up
You built a vector search engine with about 50 lines of NumPy: an index class that normalizes and stores embeddings, a search method that uses matrix multiplication to compute cosine similarity, and two visualizations that reveal the geometry behind the results.
The next step is to replace the simulated embeddings with real ones. Try loading sentence-transformers and embedding your own text corpus. The index code here will work without any changes.
If you’d like to read more “from scratch” articles, let us know what you’d like to see next!
