Building a RAG API with FastAPI

Requirements

To solve this, we need a stack that handles heavy lifting efficiently:

• FastAPI: To handle the web requests and file uploads.
• LangChain: To extend the capabilities of the LLM.
• FAISS (Facebook AI Similarity Search): Helps search through text chunks. We will use it as a vector database.
• Uvicorn: To host the server.

You can create a requirements.txt in your project and run ‘pip install -r requirements.txt’:

fastapi==0.129.0
uvicorn[standard]==0.41.0
python-multipart==0.0.22
langchain==1.2.10
langchain-community==0.4.1
langchain-openai==1.1.10
langchain-core==1.2.13
faiss-cpu==1.13.2
openai==2.21.0
pypdf==6.7.1
python-dotenv==1.2.1

Implementation Approach

We will implement two FastAPI endpoints:

1. The Ingestion Pipeline (/ingest)

When a user uploads a file, we make use of the RecursiveCharacterTextSplitter from LangChain. This function breaks long documents into smaller chunks (we will configure the function to make each chunk size as 500 characters).

These chunks are then converted into embeddings and stored in our FAISS index (vector database). We will use the local storage for FAISS so that even if the server restarts, the uploaded documents aren’t lost.

2. The Query Pipeline (/query)

When you ask a question, the question turns into a vector. We then use FAISS to retrieve the top k (usually 4) chunks of text that are most similar to the question.

Finally, we use LCEL (LangChain Expression Language) to implement the Generation component of the RAG. We send the question and those 4 chunks to gpt-4.1-mini along with our prompt to get the answer.

Python Code

In the same project folder, create two scripts, rag_pipeline.py and main.py:

rag_pipeline.py:

Imports

import os
from langchain_community.document_loaders import TextLoader, PyPDFLoader
from langchain_text_splitters import RecursiveCharacterTextSplitter
from langchain_openai import OpenAIEmbeddings, ChatOpenAI
from langchain_community.vectorstores import FAISS
from langchain_core.runnables import RunnablePassthrough, RunnableParallel
from langchain_core.output_parsers import StrOutputParser
from langchain_core.prompts import PromptTemplate
from langchain_core.documents import Document
from dotenv import load_dotenv
from typing import List

Configuration

# Loading OpenAI API key
load_dotenv()
#  Config
FAISS_INDEX_PATH = "faiss_index"
EMBEDDING_MODEL  = "text-embedding-3-small"
LLM_MODEL        = "gpt-4.1-mini"
CHUNK_SIZE       = 500
CHUNK_OVERLAP    = 50

Note: Ensure you have added the API key in the .env file

Initializations and Defining the Functions

#  Shared state
_vectorstore: FAISS | None = None
embeddings = OpenAIEmbeddings(model=EMBEDDING_MODEL)
def _load_vectorstore() -> FAISS | None:
    """Load existing FAISS index from disk if it exists."""
    global _vectorstore
    if _vectorstore is None and os.path.exists(FAISS_INDEX_PATH):
        _vectorstore = FAISS.load_local(
            FAISS_INDEX_PATH,
            embeddings,
            allow_dangerous_deserialization=True
        )
    return _vectorstore
def ingest_document(file_path: str, filename: str = "") -> int:
    """
    Chunks, Embeds, Stores in FAISS and returns the number of chunks stored.
    """
    global _vectorstore
    # 1. Load
    if file_path.endswith(".pdf"):
        loader = PyPDFLoader(file_path)
    else:
        loader = TextLoader(file_path)
    documents = loader.load()
    # Overwriting source with the filename
    display_name = filename or os.path.basename(file_path)
    for doc in documents:
        doc.metadata["source"] = display_name
    # 2. Chunk
    splitter = RecursiveCharacterTextSplitter(
        chunk_size=CHUNK_SIZE,
        chunk_overlap=CHUNK_OVERLAP,
        separators=["\n\n", "\n", ".", " ", ""]
    )
    chunks = splitter.split_documents(documents)
    # 3. Embed and Store
    if _vectorstore is None:
        _load_vectorstore()
    if _vectorstore is None:
        _vectorstore = FAISS.from_documents(chunks, embeddings)
    else:
        _vectorstore.add_documents(chunks)
    # 4. Persist to disk
    _vectorstore.save_local(FAISS_INDEX_PATH)
    return len(chunks)
def _format_docs(docs: List[Document]) -> str:
    """Concatenate document page_content to add to the prompt."""
    return "\n\n".join(doc.page_content for doc in docs)

These functions help chunking the documents, split the text into embeddings (using the embedding model: text-embedding-3-small) and store them in the FAISS index (vector store).

Defining the Retriever and Generator

def query_rag(question: str, top_k: int = 4) -> dict:
    """
    Returns answer text and source references.
    """
    vs = _load_vectorstore()
    if vs is None:
        return  _format_docs,
            "question":         RunnablePassthrough(),

    #  Retriever
    retriever = vs.as_retriever(
        search_type="similarity",
        search_kwargs=
            "source_documents": retriever,
            "context":          retriever
    )
    #  Prompt
    prompt = PromptTemplate(
        input_variables=["context", "question"],
        template="""You are a helpful assistant. Use only the context below to answer the question.
If the answer is not in the context, say "I don't know based on the provided documents."
Context:

            "source_documents": retriever,
            "context":          retriever
Question:  _format_docs,
            "question":         RunnablePassthrough(),

Answer:"""
    )
    llm = ChatOpenAI(model=LLM_MODEL, temperature=0)
    #  LCEL chain
    # Step 1:
    retrieve = RunnableParallel(
        {
            "source_documents": retriever,
            "context":          retriever | _format_docs,
            "question":         RunnablePassthrough(),
        }
    )
    # Step 2:
    answer_chain = prompt | llm | StrOutputParser()
    #  Invoke
    retrieved = retrieve.invoke(question)
    answer    = answer_chain.invoke(retrieved)
    #  Extracting sources
    sources = list({
        doc.metadata.get("source", "unknown")
        for doc in retrieved["source_documents"]
    })
    return {
        "answer":  answer,
        "sources": sources,
    }

We have implemented our RAG, which retrieves 4 documents using similarity search and passes the question, context, and prompt to the Generator (gpt-4.1-mini).

First, the relevant documents are fetched using the query, and then the answer_chain is invoked which answers the question as a string using the StrOutputParser().

Note: The top-k and question will be passed as arguments to the function.

main.py

Imports

import os
import tempfile
from fastapi import FastAPI, UploadFile, File, HTTPException
from pydantic import BaseModel
from rag_pipeline import ingest_document, query_rag

We have imported the ingest_document and query_rag functions, which will be used by the API Endpoints we will define.

Configuration

app = FastAPI(
    title="RAG API",
    description="Upload documents and query them using RAG",
    version="1.0.0"
)
ALLOWED_EXTENSIONS = {
    "application/pdf": ".pdf",
    "text/plain": ".txt",
}
class QueryRequest(BaseModel):
    question: str
    top_k: int = 4
class QueryResponse(BaseModel):
    answer: str
    sources: list[str]

Using Pydantic to strictly define the structure of inputs to the API.

 Note: Validators can be added here as well to perform certain checks (example: to check if the phone number is exactly 10 digits)

/health API

@app.get("/health", tags=["Health"])
def health():
    """Check if the API is running."""
    return {"status": "ok"}

This API is useful to confirm if the server is running.

Note: We wrap the API functions with a decorator; here, we use @app because we had initialized FastAPI with this variable earlier. Also, it’s followed by the HTTP method, here it is get(). We then pass the path for the endpoint, which is “/health” here.

 /ingest API (To take the document from the user)

@app.post("/ingest", tags=["Ingestion"], summary="Upload and index a document")
async def ingest(file: UploadFile = File(...)):
    """
    Upload a **.txt** or **.pdf** file.
    """
    if file.content_type not in ALLOWED_EXTENSIONS:
        raise HTTPException(
            status_code=400,
            detail=f"Unsupported file type '{file.content_type}'. Only .txt and .pdf are supported."
        )
    suffix = ALLOWED_EXTENSIONS[file.content_type]
    contents = await file.read()
    with tempfile.NamedTemporaryFile(delete=False, suffix=suffix) as tmp:
        tmp.write(contents)
        tmp_path = tmp.name
    try:
        num_chunks = ingest_document(tmp_path, filename=file.filename)
    except Exception as e:
        raise HTTPException(status_code=500, detail=str(e))
    finally:
        os.unlink(tmp_path)
    return {
        "message": f"Successfully ingested '{file.filename}'",
        "chunks_indexed": num_chunks
    }

This function ensures only .txt or .pdf is accepted and then calls the ingest_document() function defined in rag_pipeline.py script.

/query API (To run the RAG pipeline)

@app.post("/query", response_model=QueryResponse, tags=["Query"], summary="Ask a question about your documents")
def query(request: QueryRequest):
    """
    Ask a question related to the provided document.
    The pipeline will return the answer and the source file names used to generate it.
    """
    if not request.question.strip():
        raise HTTPException(status_code=400, detail="Question cannot be empty.")
    try:
        result = query_rag(request.question, request.top_k)
    except Exception as e:
        raise HTTPException(status_code=500, detail=str(e))
    return QueryResponse(answer=result["answer"], sources=result["sources"])

Finally, we defined the API that calls the query_rag() function and returns the response according to the documents to the user. Let’s quickly test it.

Running the App

– Run the below command on your command prompt or terminal:

uvicorn main:app --reload

Note: Ensure your environment is activated and all the dependencies are installed. Or else you might see errors related to the same.

– Now the app should be up and running here: http://127.0.0.1:8000

– Open Swagger UI (Interface) using the URL below:
http://127.0.0.1:8000/docs

Great! We can test our APIs using the interface just by passing the arguments to the APIs.

Testing Both the APIs

1. /ingest API:

Click on ‘Try it out’ and pass the demo.pdf (you can replace it with any other PDF as well). And click execute.

Great! The API processed our request and created the vector store using the PDF. You can verify the same by looking at your project folder, where you can see the new faiss_index folder.

2. /query API:

Now, click on Try it Out and pass the arguments below (Feel free to use different prompts and PDFs).

{
"question": "Name 3 applications of Machine Learning",
"top_k": 4
}

As expected, the response looks very related to the content in the PDF. You can go ahead and play with the top-k parameter and also test it out with different questions.

Understanding HTTP Status Codes

HTTP status codes inform the client whether a request was successful or if something went wrong.

Status Code Categories:

Success

*The request was successfully received and processed.

In our project:

• /health returns 200 OK when the server is running.
• /ingest and /query return 200 OK when successful.

Client Errors

*The error is caused by something the client sent.

In our project:

• If you upload an unexpected file type (not a PDF or txt file), the API returns status code 400.
• If the question is empty in /query, the API returns the status code 400.
• FastAPI returns status code 422 if the request body does not match the expected Pydantic model that we defined.

Server Errors

*They indicate something went wrong on the server side.

In our project:

• If ingestion or querying code fails due to FAISS error or OpenAI error the API returns the status code 500.

Also Read:

Conclusion

We successfully implemented and learnt to build and deploy a RAG system using FastAPI. Here we created an API that ingests PDFs/.txt’s, retrieves relevant information, and generates relevant answers. The deployment part makes GenAI systems or traditional ML systems easy to access in real-world applications. We can further improve our RAG by optimizing the chunking strategy and combining different retrieval methods for our queries
